Drum drive diagnostic
The motor runs, the drum won't turn. Five components are doing the work.
A dryer that hums or runs but won't tumble is the second most common dryer service call we make. The control board is fine, the door switch is closed, the motor is energized. But the drum sits still or thumps and barely rotates. Five components share responsibility for spinning the drum: drive belt, idler pulley, drive pulley, drum rollers, and drive motor. The diagnostic order matters because the cheapest parts (belt, idler) fail first and the expensive parts (motor, bearing) fail last.
Our techs service no-tumble dryers across LA, Orange, Ventura, San Bernardino, and Riverside. Both gas and electric (the drum drive system is identical on gas and electric models, only the heating system differs). All major brands: Whirlpool, GE, Samsung, LG, Maytag, Electrolux, Bosch, Frigidaire, KitchenAid, Miele, Thermador, Speed Queen, and others.
$89 residential diagnostic, waived with repair. BHGS #A49573. EPA 608 Universal #1346255700410. BBB A+. Phones answered 24/7.
Failure tree
Five components, ranked by failure frequency.
Listen first. The sound the dryer makes when you press start tells us which component to test first.
Quiet hum, drum spins freely by hand: drive belt
Most common no-tumble cause across all brands. The belt is a thin rubber loop that wraps around the drum, the idler pulley, and the drive pulley on the motor shaft. Year 5 to 10 typical lifespan. When it breaks, the motor runs (you hear the hum) but nothing connects the motor torque to the drum. Replacement runs $185 to $325 including idler pulley inspection. We replace belt plus idler together as a standard procedure because the idler pulley wear is what kills belts early.
Loud thumping or grinding, drum partially turns: drum rollers
Year 7 to 12 typical. Most dryers have two rear drum rollers; some have four (rear plus front). The rollers are small wheels with internal bearings that support the drum. When the bearings wear, the rollers either seize (loud grinding) or develop flat spots (loud thumping). We replace all rollers as a set ($145 to $245 installed) because partial replacement gets you a callback within months.
Squealing or grinding from idler area: idler pulley
Year 5 to 8 typical. The idler pulley keeps tension on the belt. When its internal bearing wears, it squeals during operation, then eventually seizes. A seized idler stresses the belt until it snaps. We replace idler plus belt together ($185 to $285) because doing one without the other is poor economics on a year 8+ dryer.
Silent or single click, drum doesn't move at all: drive motor
Year 12+ typical. Drive motor failures are much rarer than belt or roller failures. Symptom: complete silence when you press start, or a single click followed by silence. The motor windings have failed open. We confirm with a multimeter resistance test before quoting. Motor replacement runs $345 to $525 depending on brand.
Loud rumble that gets worse over weeks: drum bearing or rear seal
Year 10+ typical. The drum spins on a rear bearing or felt seal. When that wears, the drum scrapes the cabinet at the rear, producing a deep rumbling sound. This is the most labor-intensive dryer repair. Cost runs $245 to $385.
Diagnostic order
How we diagnose no-tumble in 15 to 25 minutes.
- Listen test. Press start. Quiet hum points to belt or motor. Loud thumping points to rollers. Squealing points to idler. Silence points to motor or door switch.
- Manual drum rotation test. With power off, rotate the drum by hand. Free spin points to belt failure. Heavy resistance points to roller seizure. Severe scraping points to drum bearing.
- Belt visual inspection. Pull off the rear or top access panel and look at the belt. Broken belt is obvious. Stretched but intact belt typically pairs with worn idler pulley.
- Idler pulley spin test. With belt off, spin the idler pulley by hand. Smooth rotation: idler okay. Grinding or wobbling: replace.
- Roller spin test. Manually rotate each drum roller. Smooth rotation: okay. Grinding, wobbling, or seized: replace as a set.
- Motor winding test. If listen test pointed to motor, multimeter ohm test on the motor windings. Open circuit: motor failed.
Once the failed component is identified, we replace it and run a no-load tumble test for 5 minutes to confirm smooth operation. The whole repair typically runs 60 to 120 minutes depending on which component failed.
Pricing
What no-tumble repairs cost.
Diagnostic is $89 (residential), waived with repair.
| Repair | Typical Cost |
|---|---|
| Diagnostic | $89, waived with repair |
| Drive belt plus idler pulley (most common no-tumble repair) | $185 to $325 |
| Drum rollers (full set replacement) | $145 to $245 |
| Belt plus idler plus rollers (year 10+ multi-component) | $285 to $445 |
| Drive motor replacement | $345 to $525 |
| Drum bearing or rear seal | $245 to $385 |
| Drive pulley | $125 to $185 |
| Door switch (if no-tumble caused by safety lockout) | $125 to $185 |
| Warranty | 90 days parts and labor |
Brand notes
No-tumble patterns by brand.
- Whirlpool, Maytag, KitchenAid (Whirlpool family). 29-inch belt is the standard wear part. Drum rollers at year 8 to 10 typical. Cabrio and Duet families share the same drum drive parts platform.
- GE. 27-inch belt standard. Idler pulley wear pattern at year 6 to 8 is the dominant cause of belt breakage on GE units.
- Samsung. DV series uses a unique tensioner design. Belt failures often come from tensioner spring fatigue. We replace spring and belt together on year 8+ Samsung dryers.
- LG. DLE and DLG models share parts. Drum bearing pattern at year 10 to 12 is more visible on LG than other brands because the bearing design has less margin.
- Electrolux, Frigidaire (Electrolux family). Drum roller failures dominate. The roller bearings on this platform have a year 7 to 9 wear pattern that's tighter than other brands.
- Bosch. European-architecture dryers have a different drum drive layout. Belt and roller diagnostic principles still apply, but parts platforms differ from US-market brands.
- Miele, Thermador. Premium tier. Drum drive components last year 12 to 15 typical. Parts cost more but availability through SoCal distribution is solid.
- Speed Queen. Built tougher. Belt and roller pattern often year 12+. When they do fail, parts are easy to source and labor is straightforward.
FAQ
Dryer not-tumbling questions.
My dryer hums but the drum won't turn. What's wrong?
The two most likely causes are a broken drive belt (most common, year 5 to 10 typical) or a seized drum roller (year 7 to 12). A broken belt produces a quiet hum or no sound at all when you press start. A seized drum roller produces a loud thumping or grinding sound. We test both at the diagnostic visit by manually rotating the drum: free movement points to belt, resistance points to rollers.
I hear a thumping sound and the drum barely turns. What is that?
Worn drum rollers, almost always. Most dryers have two or four rollers (small wheels) that support the rear or front of the drum. When the bearings wear out, the rollers seize or develop flat spots, which causes the thumping. Replace all rollers as a set, not just the failed one, because the others are typically a few months from failing too. Roller kits run $145 to $245 installed.
Can I replace the dryer belt myself?
Mechanically yes for handy homeowners, but the belt itself is the cheapest part of the repair. The reason belts break early is usually a worn idler pulley or a degraded drum roller, both of which need to be inspected and often replaced at the same time. We replace belt plus idler pulley together as a standard procedure, because replacing the belt alone on a year 8 dryer typically gets you a callback in 6 to 12 months.
What's the difference between belt failure and motor failure?
Belt failure: motor runs (you hear it humming), drum doesn't turn, drum spins freely by hand. Motor failure: motor doesn't run at all (silent or clicks once and stops), drum may or may not turn freely by hand. Motor failures are much rarer (year 12+ typical) and almost always come with a burnt-electronics smell. We test motor windings with a multimeter to confirm before quoting a motor replacement.
What's the typical cost?
Belt plus idler pulley replacement (most common no-tumble repair): $185 to $325 depending on brand and access. Drum roller kit: $145 to $245. Drive motor replacement: $345 to $525 (parts cost varies by brand). Drum bearing or rear seal: $245 to $385. Multi-component repair on a year 10+ unit: $385 to $525. The $89 diagnostic is waived when you approve the repair.
When should I replace the dryer instead of repairing the drum drive?
Mid-tier dryer (under $700 retail) at year 12+ with motor failure or drum bearing failure: replacement is often the right call. Belt or roller failures alone almost always favor repair regardless of age because the labor is short and parts are inexpensive. Premium tier (Miele, Bosch, LG WashTower, Samsung Bespoke): repair through year 12 makes sense even for motor failures.
What's your warranty?
Ninety days SDAR labor and parts warranty on the work we perform. If the same component fails within 90 days, we replace it free. BHGS #A49573 and BBB A+ accredited. EPA 608 Universal #1346255700410.
